3.f.5.3 Communication Work Mode (P4.5.3):
This parameter defines the functions of and buttons on the panel. 2 modes, “Acknowledged” and “Not acknowledged”
may be selected. These modes are explained below :
Acknowledges to transfer the
control of CCS 3000 start/stop and
load valve to remote controller
such as ENKO SCADA software.
No effect. When CCS 3000 is remotely
connected, the start/stop and load valve
controls are automatically transferred to
the remote controller such as ENKO
SCADA software.
No effect. When CCS 3000 is remotely
connected, the start/stop and load valve
controls are automatically transferred to
the remote controller such as ENKO
SCADA software.
3.f.5.4 Modbus Address (P4.5.4):
It sets the address of RS-485 port on CCS 3000. Can be assigned between 1 and 100.
3.f.5.5 Baud Rate (P4.5.5)
It sets the baud rate of RS-485 port on CCS3000. The selectable rates are 2400 bps, 4800 bps, 9600 bps, 19200 bps,
3.f.5.6 Stop Bit (P4.5.6)
It sets the number of stop bits on RS-485 port of CCS3000. Can be assigned as 1 or 2.
3.f.5.7 Parity Bit (P4.5.7)
It determines parity bit control of RS-485 port on CCS3000. It may be Even or Odd. Parity Bit control is disabled when this
parameter is set to “Disable”.
3.f.5.8 Timeout Duration (P4.5.8)
If the communication breaks down or is not established during the duration set in this parameter, CCS3000 transfers the
start/stop control to the panel and control of load valve to the sensor.
3.f.6 Calibration Parameters (P4.6)
3.f.6.1 Pressure Offset (P4.6.1) (Bar/PSI):
This parameter is used to calibrate the line pressure sensor. Can be set between -1 and +1.
3.f.6.2 Temperature Offset (P4.6.2) (Cel/Fah):
This parameter is used to calibrate the temperature sensor. Can be set between -10 and +10.
3.f.6.3 Screw Pressure Offset (P4.6.3) (Bar/PSI):
This parameter is used to calibrate the screw pressure sensor. Can be set between -1 and +1.
