CCS3000 Mechanical Dimensions and Technical Specifications

Power Supply

10 –30 Vac

Operating

Temperature

-10C / +60C

Relay Outputs

OUT0-OUT3 Relay Output (6A 250Vac cos =1.0)

OUT4 Changeover Relay Output (10A 250Vac cos =1.0)

Connection

Screw-free Socket

Housing

Metal Back Cover 0.8mm

Plastic Front Cover 2 mm

Weight

550 gr. (approx..)

Dimensions (WxHxD)

174 x 124 x 39.8 mm

Panel Cutout

151.6 x 115.6mm

Installation

Panel mounting, fixing with metal screw
