TECHNICAL DATA
Chart 1: Dispenser technical data
Description Measure unit Value
Dimensions
Length (L) mm 750
Height (H) mm 640
Width (S) mm 240
Weight kg 42
Dispenser features
Number of bottle 4
Wine preservation temperature °C 7÷18
Electrical power W 150
Electrical voltage V 110-220
Electrical frequency Hz 50-60
Auxiliary circuit voltage Vdc 24
Protection rate IP 20
Fuses quantity 2
Fuses value
A (220V) 4
A (110V) 8
Gas (air/nitrogen) duty pressure for bottle lifting line bar 4
Gas (argon/nitrogen) duty pressure for wine dispensing
line
bar 0,160
Bottle features
Height mm 280÷355
Maximal diameter mm 100
