Use and maintenance manual
6 - INTRODUCTION
DANGER
To signal a probably dangerous situation regarding the health of the operator and others (slight injuries or accidents) or the efficiency of the rake;
The writing Note indicates that the treated matter can make it easier for the operators to carry out their work.
A3 Identification and CE mark
Every equipment is provided with an identification plate applied on the frame and clearly visible, on which the following data is reported:
- the model (and/or version) of the rake;
- serial number;
- minimum power of the tractor (kw);
- total weight (kg);
- year of manufacture.
This data must be quoted every time requesting assistance and spare parts.
IMPORTANT
It is strictly forbidden to alter and/or delete the data on the identification plate. However, the operator
must often verify legibility of the data and, when precarious, inform the Manufacturer. The manufacturer
will place the data on a new plate and replace the previous one.
The CE mark indicates the manufacturer has complied with the dispositions the Member states of the
European Community has adopted on the health and safety and that is known as “Machinery Directive”. This means the manufacturer has designed and
manufactured the equipment in the full respect of all requisites for its use and to avoid all possible deriving risks and dangers. Therefore, the hay rank can
freely circulate on the European territory only if provided with this mark and relative declaration of conformity.
A4 Main components and technical data
1. Mechanical end stop (for adjusting the weight of the wheels to the ground)
2. Spring
3. Rear wheel
4. Hay wheel
5. Fixed frame
6. Hydraulic quick couplers
7. Central wheel
8. Coupling device fdor tractor hitch
9. Mechanical lock for cylinder (only for transport)
10. Front wheel
11. Mechanical lock for opening mobile frame (only for transport)
