IQ System Controller 3/3G Quick Install Guide
What’s in the box
IQ System Controller 3/3G Wall-mounting bracket System Shutdown Switch
Comes pre-wired with 4 x 20 ft.
color-coded wires.
Accessory kit
ITEM NAME ITEM CATEGORY DESCRIPTION QUANTITY
Filler Cover Mounting BKT-L 200G Enpower Plastic part Filler Cover Mounting BKT-L 200G 2
Filler Cover Mounting BKT-R 200G Enpower Plastic part Filler Cover Mounting BKT-R 200G 2
Screw, Pan Hd, Phillips #3, M6 x 25 mm Lg (5 mm
Shank - 20 mm Thread), Machine, 304 SS
Fastener
Screw, Pan Hd, Phillips #3, M6 x 25 mm
Lg (5 mm Shank - 20 mm Thread),
Machine, 304 SS
2
Screw, Pan Hd, Torx X20, Machine,
#8-32 UNC, 0.63" Lg, A2-70
Fastener
Screw, Pan Hd, Torx X20, Machine,
#8-32 UNC, 0.63" Lg, A2-70
1
Lit Kit Label, Enpower 200G Label Lit Kit Label, IQ System Controller 200G 1
Label, Enpower, CT Field Label 6
Label, Enpower, PCS Field Label 2
Feed-through header with Cable Assy Header
Enpower 200G R2
Cable assembly
System Shutdown feed-through
header with cable assembly
1
NEC Labels for Rapid Shutdown Label
Labels required as per NEC
for Rapid Shutdown
2
