IQ System Controller 3/3G Quick Install Guide
11
Tools/additional
items required
S. NO ITEM NAME QUANTITY SOURCE
1 CT-200-CLAMP 3 IQ Combiner/Enphase Store
2 EP200G-HNDL-R1 (lifting handle) 1 Enphase Store
3 Breakers, dierent ratings 4 Enphase Store/retail outlets
4 Conduits (with ttings and tting tools) As required Provided by installer
5 Drill 1 Provided by installer
6 5/32" pilot bit 1 Provided by installer
7 Screwdriver 1 Provided by installer
8 Wrench 1 Provided by installer
9 Adjustable wrench 1 Provided by installer
10 Torque wrench 1 Provided by installer
11 Level 1 Provided by installer
12 5/32" Allen key 1 Provided by installer
13 Conductor stripper 1 Provided by installer
14 Electrician’s hole saw (2") or punch set 1 Provided by installer
15 Stud nder (if required) 1 Provided by installer
16 Conduit ground hub rings 1 Provided by installer
17
#10,1/4" or 5/16" lag bolts or screw 3" long (depending
on attaching wall) for each wall-mount bracket
As required Provided by installer
18 Control wire As required Distribution/Enphase Store*
* Enphase SKU for control cable: CTRL-SC3-NA-01
