IQ System Controller 3/3G Quick Install Guide
Main lugs
Neutral terminals
Ground terminals
Load center for
DER breakers
Backup lugs
AUX and System
Shutdown terminals
Terminals for
DER cables
Internal view of
IQ System Controller 3/3G
The following gure shows the IQ System Controller 3/3G after
the dead front is removed. It comes with an inbuilt neutral forming
transformer, microgrid interconnection device, automatic transfer
switch, and a panel board to mount plug-in type breakers.
Section B
Mounting the breakers
Hold-down kit
