Installing an Optional PoE Module in the G3G124-24 Switch
Enterasys G-Series Hardware Installation Guide 2-23
c. FordetailsonhowtoconfiguretheG‐Seriesusingthecommandlineinterface,refertothe
EnterasysG‐SeriesCLIReference.TheCLIcommandsenableyoutosetanewpasswordand
performmoreinvolvedmanagementconfigurationsontheG‐Series.
Ifyourequireassistance,contactEnterasysNetworksusing
oneofthemethodsdescribedin
“GettingHelp”onpage xvii.
Installing an Optional PoE Module in the G3G124-24 Switch
InstallingPoEcapabilityintheG3G124‐24baseswitchrequiressignificantdisassemblyofthe
switch.BeforeinstallingthePoEmodule,youmustcompletethefollowingsteps:
1. Unplugallpowerandnetworkconnectionstotheswitch.
2. RemoveIOM(s).Referto“RemovinganIOM”onpage 2‐13.
3. Removepowersupplies.Referto“Removing
aPowerSupply”onpage 2‐9.
4. Removeandretainscrewssecuringtheswitchcovertopandcompactflashcoverplateand
removetheswitchcover.Referto“RemovingtheSwitchCover”onpage 2‐23.
Removing the Switch Cover
IfyouhavepurchasedanoptionalPoEmodule(G3G‐POE),haveunpluggedallnetworkand
powerconnectionsandremovedpowersupplies,youmustremovetheswitchcoverasfollowsto
accessthePoEboardconnectorsintheG3G124‐24basechassis.
1. RefertoFigure 2‐12onpage 2‐24tolocateall
screwsnecessaryforremovingthecover.
Note: It is strongly recommended that you change the admin password from its default state of
blank (no password), once the G-Series switch becomes operational in your network. For more
information, refer to the Enterasys G-Series CLI Reference
.
Note: Instructions for installing PoE on the base switch do not apply to the G3G124-24P model
since it is already equipped with a PoE card.
Caution: Be sure to retain all screws removed from the G-Series switch cover in a secure location
to avoid misplacing them. Leaving any loose screws inside the switch could result in severe
damage to switch components.
Precaución: Asegúrese de colocar todos los tornillos que haya retirado de la cubierta del switch G-
Series en un lugar seguro, para evitar perderlos. Cualquier tornillo suelto que se deje en el interior
del switch podría dañar sus componentes.
