Enthermics DC250 - Page 23

21
MN-37072 • Rev 2 • 05/16 • Designer Series Blanket Warmer
Dimension Drawings
DC350 with standard feet
Dimensions (H x W x D)
With feet (standard): 27.9" x 18.5" x 25.7" (709mm x 470mm x 653mm)
With plate and
casters
(optional):
32.2" x 18.5" x 25.7" (819mm x 470mm x 653mm)
With bumper and
casters
(optional):
32.2" x 21.3" x 25.9" (819mm x 540mm x 657mm)
Capacity
3.5 
3
Weight**
(est.)
Net: 91 lbs (41 kg) Ship: 146 lbs (66 kg)
Electrical
*Other international plugs are available, contact factory for more information.
**Domestic ground shipping information. Contact factory for export weight and dimensions.
120 V.A.C. — 60 Hz, 1 ph
0.8 kW, 6.7 Amps
Safety Class I Equipment
No Applied Parts
Mode of Operation: Continuous
NEMA 5-15P
15A - 125V Plug
Hospital Grade
IPX-0
E471516
220 V.A.C. — 50Hz, 1 ph
0.8 kW, 3.6 Amps
Type B Equipment
CEE 7/7*
220-230V Plug
IPX-0
230 V.A.C. — 50 Hz, 1 ph
0.8 kW, 3.5 Amps
Type B Equipment
BS 1363 Plug*
(UK only)
CEE 7/7*
220-230V Plug
IPX-0
**Domestic ground shipping information. Contact factory for export weight and dimensions.
9.3 " (235mm)
IEC Cord Inlet
18.0" (457mm)
18.5" (470mm)
CAVITY
22.2" (564mm)15.5" (394mm)
CAVITY
14.5" (369mm)
INSERT
18.5" (470mm)
21.1" (537mm)
CAVITY
9.6" (244mm)
INSERT
27.2" (691mm) 27.9" (709mm)
9.6" (244mm)
INSERT
22.8" (580mm)
42.3" (1073mm)
36.0" (914mm)
Cord length: 6 ft (1.83m) (est.)
24.5
" (621mm)
IEC Cord Inlet
25.7" (653mm)
Clearance requirements:
3" (76mm) from rear
1" (25mm) from top and sides
3/4" (19mm) from bottom
