23
MN-37072 • Rev 2 • 05/16 • Designer Series Blanket Warmer
Dimension Drawings
DC350 with optional bumpers and casters
18.5" (470mm)
CAVITY
25.1" (638mm)
21.3" (540mm)
14.5" (369mm)
INSERT
18.5" (470mm)
21.1" (537mm)
CAVITY
9.6" (244mm)
INSERT
27.2" (691mm)
9.6" (244mm)
INSERT
22.8" (580mm)
5.0" (128mm)
32.2" (819mm)
15.5" (394mm)
CAVITY
10.6 " (270mm)
IEC Cord Inlet
18.0" (457mm)
42.2" (1072mm)
37.3 " (948mm)
Cord length: 6 ft (1.83m) (est.)
28.8
" (730mm)
IEC Cord Inlet
25.7" (653mm)
25.9" (657mm)
Clearance requirements:
3" (76mm) from rear
1" (25mm) from top and sides
3/4" (19mm) from bottom
#5017546 (white epoxy coated) – 3" (76mm) casters (2 rigid, 2 swivel with brake)
#5017548 (stainless steel) – 3" (76mm) casters (2 rigid, 2 swivel with brake)
