MN-37072 • Rev 2 • 05/16 • Designer Series Blanket Warmer
DC400 with optional bumpers and casters
13.4 " (339mm)
IEC Cord Inlet
23.5" (597mm)
50.0" (1270mm)
48.4" (1229mm)
21.2" (539mm)
21.0" (533mm)
CAVITY
20" (507mm)
INSERT
24" (610mm)
21.0" (533mm)
CAVITY
25.1" (638mm)
14.6" (372mm)
INSERT
15.1" (384mm)
CAVITY
27.4" (695mm)
5.0" (127mm)
26.2" (665mm)
Cord length: 6 ft (1.83m) (est.)
26.8" (679mm)
22.8
" (578mm)
IEC Cord Inlet
28.9" (734mm)
28.0" (712mm)
Clearance requirements:
3" (76mm) from rear
1" (25mm) from top and sides
3/4" (19mm) from bottom
#5017547 (white epoxy coated) – 3" (76mm) casters (2 rigid, 2 swivel with brake)
#5017549 (stainless steel) – 3" (76mm) casters (2 rigid, 2 swivel with brake)
