27
MN-37072 • Rev 2 • 05/16 • Designer Series Blanket Warmer
Dimension Drawings
DC750 with standard feet
12.0 " (305mm)
IEC Cord Inlet
23.5" (597mm)
21.0" (533mm)
CAVITY
34.3" (871mm) 35.4" (900mm)
21.0" (533mm)
CAVITY
19.9" (506mm)
INSERT
24.0" (610mm)
28.1" (715mm)
CAVITY
13.1" (333mm)
INSERT
13.2" (336mm)
INSERT
25.1" (637mm)
50.0" (1270mm)
47.0" (1194mm)
Cord length: 6 ft (1.83m) (est.)
31.8
" (807mm)
IEC Cord Inlet
28.0" (712mm)
24.2" (614mm)
Dimensions
(H x W x D)
With feet (standard): 35.4" x 24.0" x 28.0" (900mm x 610mm x 712mm)
With bumper and
casters
(optional):
39.3" x 26.8" x 28.0" (997mm x 679mm x 712mm)
With casters
(optional): 40.7" x 24.0" x 28.0" (1033mm x 610mm x 712mm)
Capacity
7.5 
3
Weight**
(est.)
Net: 134 lbs (61 kg) Ship: 196 lbs (89 kg)
Electrical
*Other international plugs are available, contact factory for more information.
**Domestic ground shipping information. Contact factory for export weight and dimensions.
120 V.A.C. — 60 Hz, 1 ph
0.8 kW, 6.7 Amps
Safety Class I Equipment
No Applied Parts
Mode of Operation: Continuous
NEMA 5-15P
15A - 125V Plug
Hospital Grade
IPX-0
E471516
220 V.A.C. — 50Hz, 1 ph
0.8 kW, 3.6 Amps
Type B Equipment
CEE 7/7*
220-230V Plug
IPX-0
230 V.A.C. — 50 Hz, 1 ph
0.8 kW, 3.5 Amps
Type B Equipment
BS 1363 Plug*
(UK only)
CEE 7/7*
220-230V Plug
IPX-0
**Domestic ground shipping information. Contact factory for export weight and dimensions.
Clearance requirements:
3" (76mm) from rear
1" (25mm) from top and sides
3/4" (19mm) from bottom
