MN-37072 • Rev 2 • 05/16 • Designer Series Blanket Warmer
Service
Part numbers and drawings are subject to change without notice.
Serial number is required for all inquiries.
Always include both model and serial number(s) in any
correspondence regarding the appliance.
Model: ______________________________________________
Serial Number: ______________________________________________
Purchased From: ______________________________________________
Date Installed: ____________________ Voltage: _____________
Full Assembly C
10
19
18
17
21
9
16
15
11
12
20
10
19
18
17
21
9
16
15
11
12
20
Item Description Part Qty
9 Chassis, 3-zone, 120V, 1.5
3
/2.5
3
5017792 1
9a Chassis, 3-zone, 230V, 1.5
3
/2.5
3
5017795 1
9b Chassis, 4-zone, 120V, 3.5
3
/4.03/7.5
3
5017793 1
9c Chassis, 4-zone, 230V, 3.5
3
/4.03/7.5
3
5017796 1
10 Bumper feet, rubber, 1.5
3
/2.5
3
/3.5
3
/4.0
3
FE-29203 4
10a Bumper feet, rubber, 7.5
3
BM-22606 4
11 Heater pad, with pad sensor and pad hi-limit, 1.5
3
/2.5
3
EL-37009 3
11a Heater pad, with pad sensor and pad hi-limit, 3.5
3
/4.0
3
EL-37009 4
11b Heater pad, with pad sensor and pad hi-limit, 7.5
3
EL-36692 4
12 Insulation kit, 1.5
3
5018010 1
12a Insulation kit, 2.5
3
/3.5
3
5018011 1
12b Insulation kit, 4.0
3
/7.5
3
5018012 1
Item Description
13 Spring, door, 1.5
3
SD-29340 1
13a Spring, door, 2.5
3
/3.5
3
/4.0
3
/7.5
3
SD-29467 1
14 Service kit, upper hinge, RH 5015522 1
15 Service kit, lower hinge, RH 5015523 1
16 Screw, M8 x 1.25 x 20mm hex flange SC-27046 6
17 Plug, 1/2" hole PG-3344 1
18 Power, switch, assembly SW-34911 1
19 Fuse, (F1, F2) fast acting FU-34955 2
20 Power cord, NEMA 5-15P, 120V CD-35030 1
Part
Qty
1616
1613
1614
21 Clip, panel retainer CL-29193 6
Power cord, CEE 7/7, 220/230V CD-3984 1
Power cord, BS 1363, 230V CD-29714 1
20a
20b
