Enthermics EC1850BL - Dimension Drawings

SPECIFICATIONS
Combinat ion Blan ke t/F luid W a rmer ▪ Operato r’s Man ual ▪ M N-399 40 ▪ Rev 3 ▪ 8/ 20
14
Dimension Drawings
EC1350BL Reach-In
EC-DIM-008782
15
"
(381mm)
WITHOUT INSERT
36
"
(914mm)
WITHOUT INSERT
34.75
"
(882.75mm)
INSERT
59.5 " (1511mm)
29
"
(737mm)
48.5
"
(1232mm)
19.75 " (501.75mm)
21.25 " (539.75mm)
72.75
"
(1847.75mm)
IEC Cord Inlet
17 " (432mm)
CAVITY
17 " (432mm)
CAVITY
75
"
(1905mm)
30 " (763mm)
26.5 " (673mm)
CAVITY
13.75
"
(349.25mm)
INSERT
26.5 " (673mm)
CAVITY
