ENTR Dead Bolt - 1.4 Cylinder & Unit Installation

7
ENTR® Dead Bolt User Manual
Adapter
• Place the Inside drive adapterandghtenthe
screws.Donotoverghtenthescrewsoruse
power tools.
• Placedecoravespaceroverthe
Inside drive adapter.
• Assemblebaseplate(top
housing&knob).
• Tightencylindermounngscrew.
Note: Incasethe"Malerectangle"ontheadapterisnotalignedwiththe"Female
rectangle"ontheKnob,theunitwillnotengageproperlyandmaycausetomalfuncon.
Femalerectangle
Adapter
Mounngscrew
Base plate
Decoravespacer
Malerectangle
Femalerectangle
Adapter
