ENTR Dead Bolt - Magnet Fitting

8
ENTR® Dead Bolt User Manual
1.5 Magnet Fing
• Carefullyconnectdatacableplug.
• Assembleelectricalunitpanel(baeryhousing).aachetobase
plate(1)andpushdown(2).
• Tightenelectricalunitpanelscrew.
Electrical unit
Datacableplug
1
Panel screw
2
MagnetFing:
• Mountthemagnetontheframe
moldings,ascloseaspossibleto
the lock.
• Thelowerpartofthemagnetshould
alignwiththelowerpointoftheslider
(seeillustraon).
Note:Themagnetareaonframemolding
shouldbecleanandfreefromdust,
peelingpaintetc.Usealcoholifrequired.
Waitunlcompletelydrypriortoscking.
Frame
molding
Magnet
Slider
