32
IP2045EN - 2014-09-22
Jumper Description
OFF
ON
JR3 Incorporated radio receiver. Disabled. Enabled.
JR4 Overtravel reduction.
Reduces the overtravel distance
for the door wing.
Disabled. Enabled.
NOTE: preferably set JR4=ON
if the door wing performs an
excessive overtravel.
JR6 Application type. Sliding gate. Other applications.
JR10 Maximum power start. Disabled.
The motor starts with the voltage
set with RF.
Enabled.
The motor starts at maximum
power for 1 s.
NIO Electronic antifreeze system.
Maintains motor function even
at low ambient temperatures.
NOTE: for correct operation, the
control panel must be exposed
to the same ambient tempera-
ture as the motors.
Enabled.
ATTENTION: do not use with
E1AJ.
Disabled.
SO Reversal safety switch function. With the automation blocked,
if the contacts 1-8 or 41-8 are
open, it is possible to activate the
opening operation.
NOTE: after the activation of the
proximity limit switch closes the
opening of the safety contact 1-8,
41-8 provokes the STOP during
the closing phase.
With the automation blocked, if
the contacts 1-8 or 41-8 are open,
any operation is impossible.
6→4 Control 1-6 function. Closing. Stop.
6.2 Dip-switch
DIP Description
OFF
ON
DIP1 Control 1-5 function. Step-by-Step. Opening.
DIP2 Direction selection. Opens towards right. Opens towards left.
DIP3 Restore automatic closing time. 50% 100%
NOTE: the setting of DIP3=ON is
recommended for overhead and
sectional doors, and condomi-
nial entrances.
Immediate if 6→4=OFF.
NOTE: the setting of DIP3=OFF
and 6→4=OFF is recommended
for the immediate reclosing of
the barriers.
DIP4 Automation status at power on.
Indicates how the control panel
considers automation when po-
wered up.
Open.
If DIP1=OFF, the first command
1-5 activates the closing.
If DIP1=ON, the first command 1-5
activates the opening.
NOTE: with a limit switch instal-
led, preferably set DIP4=OFF.
Closed.
The first command 1-5 activates
the opening.
NOTE: the automatic closing will
not be the first command, even
if enabled.
If the automatic closing function is
not used, preferably set DIP4=ON.
6.3 Jumper
