• Bridge the NC safety contacts with a jumper.
• Before starting up, check the application type selected (see JR6 jumper).
• Any limit switches installed must be adjusted so that they are triggered near the mechanical
opening and closing end stops. Set TM=MAX.
NOTE: limit switches must be kept pressed until the operation has been completed.
• If no limit switches are installed, bridge terminals 0-11 and 0-12 with jumpers and set TM to
half.
• Set TC=MAX. Set RF=CT-3 and R1 to half.
• Using DIP2, set the direction.
• Switch on power.
• Perform opening and closing commands and check that the automation functions correctly
and that the limit switches (if installed) are correctly set.
NOTE: if mechanical stops are used to block the stroke of the automation, or a proximity limit switch
with N.O. contact, adjust the TM trimmer in order to obtain an operation time 2-3 s greater than
the time effectively taken by the automation.
• Connect the safety devices (removing the relative jumpers) and check that they function correctly.
• If required, regulate the automatic closing by means of the TC trimmer.
• Set RF to a position that allows the automation to function correctly while ensuring the safety
of the user in the event of collision.
• Set obstacle thrust with R1.
• NOTE: ensure that the forces exerted by the door wings are compliant with EN12453-EN12445
regulations.
• Connect any other accessories and check operation.
• Once the start up and check procedures are completed, close the container.
WARNING: The following operations are performed with no safety devices.
8. Starting
