Envicool XRow Series - Arrival Inspection; Mechanical Parameters

Shenzhen Envicool Technology Co., Ltd.
7
Table 2-2 Operation environment requirement
Item
Requirement
Installation mode
Indoor unit: vertical installation; Outdoor unit: vertical installation; Refrigerant pump:
vertical installation
Connecting pipe length
The longest horizontal pipeline length of XRow unit: 60m
Drop height
The outdoor unit is above the indoor unit (positive drop), the nominal maximum height
difference: 30m, the nominal maximum pipe equivalent length: 60m;
The outdoor unit is below the indoor unit (negative drop), the nominal maximum height
difference: 10m, the nominal maximum pipe equivalent length: 60m..
Indoor ambient temperature
18ºC~40ºC
Outdoor ambient temperature
-15ºC~45ºC
Relative humidity
20%RH~80%RH
IP class of outdoor unit
IPX4
Altitude
<1000m, derated when the altitude exceeds 1000m
Operating voltage range
Three-phase power supply: 380V(-15%~+15%), Frequency: 50Hz (± 2.5Hz)
Note: If the relevant values in the actual application exceed the recommended values in the
above tables, please consult the technical department of our company.
2.1.2 Arrival inspection
If possible, move the equipment to the place closest to its final installation location before
unpacking. All the parts are shipped out after packing. When you receive the XR series
products, you need to check whether all the parts are in good condition. If you find any damage
during unpacking, please report it to the carrier immediately. If you find any concealed damage,
please also report it to the transportation company and the air-conditioning equipment
company.
2.2 Mechanical parameters
 Warning
You must strictly comply with the recommended installation and maintenance space requirement of
the relevant equipment.
You should decide whether to modify the building to facilitate the piping, cabling and duct
construction.
