Envicool XRow Series - Indoor Unit Power Cable Connection

Shenzhen Envicool Technology Co., Ltd.
35
Table 2-18 Optional ammeters for power-off switches of power distribution cabinets of various types
of units
2.6.1 Indoor unit power cable connection
The unit adopts a three-phase five-wire system. The input power A/B/C is connected to
the A/B/C of the main circuit breaker of the indoor unit, and the N and PE are respectively
connected to the terminal block, as shown in Figure 2-24.
Model
Optional current value （A）
Indoor unit
XR023A
Cooling
32
Cooling and heating
40
Cooling, heating and humidifying
40
XR040A
Cooling
50
Cooling and heating
63
Cooling, heating and humidifying
63
XR050A
Cooling
63
Cooling and heating
80
Cooling, heating and humidifying
80
outdoor unit
CS38/CS46/CS54/CS66/CS78/CS86
10
CS38U/CS46U/CS54U/CS66U/CS78U/CS86U
10
CS38P/CS46U/CS54P/CS66P/CS78P/CS86P
10
IF pump cabinet
IFP1C
10
IFP3C
10
IFP5C
10
