Shenzhen Envicool Technology Co., Ltd.
2.5.5 Connection of the water supply pipe of the humidifier
(optional)
The unit provides a quick connector for the water supply pipe (1/2" GAS female thread) of the
humidifier. The users are suggested to install the cut-off valve and water supply filter for the
water supply pipe to isolate the humidifier during the maintenance.
1. The water supply shall adopt the ordinary tap water with the conductivity within the range of
300μS/cm~1250μS/cm.
2. The water supply pressure for the humidifier system shall be 0.1~0.8MPa.
2.5.6 Removal of compressor footer holder
The four footers of the compressor are equipped with the vibration isolating rubber gasket to
reduce the vibration during the compressor operation. To prevent the compressor shaking
during the transportation and the resulting pipe damage, three footers of the compressor are
mounted with holders upon the delivery of the unit. The three holders are used for
transportation only, and must be removed when installing the unit. The footer fixing bolts shall
be tightened after the three holders are removed. The schematic diagram for the removal of the
footer holders is as shown in Fig.2-23.
Fig. 2-23 Schematic diagram for the removal of the compressor footer holder
If the compressor runs before the holders are removed, large vibration will be caused.
