Envicool XRow Series - Page 15

Shenzhen Envicool Technology Co., Ltd.
10
Model
A
B
C
D
E
F
G
H
I
J
Fans
CS78
2410
2230
2130
1269
1220
1120
1099
651
2240
250
2
CS86
2410
2230
2130
1269
1220
1120
1136
688
2240
250
2
Fig. 2-4 V-type condenser dimensions
Table 2-5 V-type condenser dimensions (unit: mm)
Model
W
L
H
CS38U
1020
1020
1840
CS46U
1020
1020
1840
CS54U
1020
1020
1840
CS66U
1080
1080
2000
CS78U
1080
1080
2000
CS86U
1080
1080
2000
Fig. 2-4 Dimensional drawing of V-type condenser with pump cabinet
