Envicool XRow Series - Page 49

Shenzhen Envicool Technology Co., Ltd.
44
Figure 2-24 Schematic diagram of solenoid valve wiring for cryogenic components
2.6.5.9 Liquid pipe solenoid valve communication (optional)
The liquid pipe solenoid valve control line is connected from the X3/X4 terminal in the
room, and the wiring diagram is shown in 2-25.
