Pulse oximeter MySign
®
S
5 Operating elements and symbols
The system is operated using the membrane keys on the front. All of the system's status and error messages are
shown in plain text on the illuminated screen.
Front Back
No. Description No. Description
c
Housing
h
ON/OFF key
d
Display
i
Sensor socket
e
Operating keys
j
Sound emitter
f
USB port
k
Support
g
Alarm LED red/yellow
