Pulse oximeter MySign
®
S
5.1 Keys and LEDs
+
Function keys 1 + 2 (depending on menu)
Example:
Function 1 Function 2
Select key UP
For selecting menu items and changing parameters
(Pulse sound Î louder)
Select key DOWN
For selecting menu items and changing parameters
(Pulse sound Î quieter or off)
Main menu or home key
Opens the main menu or brings you back to the main screen
“Pause audio alarm” key with yellow LED
Acknowledges an alarm Î Mutes it for 120 seconds
Pressing this key briefly twice (double-click) fully switches off the
current audio alarm.
+
Switches the audio alarm off!
LED on Î as soon as the audio alarm has been switched off.
LED flashes Î as soon as the reminder signal has also been switched off.
ON/OFF key
For switching the unit on / off
Alarm LED red/yellow
Visual signals, see “10. Alarm signals”
16 066-07-1002197_GA_MySignS_FDA / 06.14
