FIKE CORPORATION
FM 3020541 Fike Explosion Protection System Page 23 of 32
P/N E06-051 Rev. 8 10/06
8.0 EPC SPARE PARTS
Part Number Description
E10-0066 Explosion Protection Controller (EPC)
02-4181 Fuse, 2A mini automotive blade type
10-2457 End of Line Resistor, 820 Ω, 0.5 Watt (P3 & P4)
10-2458 Wire Supervision Device, 240 Ω, 0.5 Watt (P4)
10-2459 Series Contact Device, 2.4V Zener Diode (P3 & P4)
10-2523 Transducer Simulator (P2)*
02-10415 Six (6) Position Wire Terminal Block (P1, P3 & P6)
02-10417 Three (3) Position Wire Terminal Block (P2, P4 & P5)
02-10876 End of Line Resistor, 140 Ω, 0.5 Watt (P1)
*WARNING: Transducer Simulator must
be removed when a transducer is connected to the P2 input(s).
Exhibit 8-1 Spare Parts List
