13
WARNING: The voltage parameters of a lithium battery can be set according
to the voltage parameters of lithium battery BMS.
WARNING: The required accuracy of BMS shall be no higher than 0.2V. We
will not assume any responsibility for the system abnormal when the
accuracy of BMS is higher than 0.2 v.
2.5 Load output voltage and priority setting
Load working
Modes
(only valid for load 2)
Charging prior mode (Default)
CPM(Charging Prior Mode)
Load prior mode
①
LPM(Load Prior Mode)
① The load prior mode will be enabled when the battery voltage reaches the low voltage disconnect
voltage, and the PV array charging current reaches more than 7A for 10 minutes.
WARNING: Before connecting loads, ensure the voltage level of load is
equal to the output voltage level corresponding to the DIP switch. If the
output voltage level is higher than the load voltage, the load may be
damaged.
