5 Specifications
Electrical Parameters
Model
MSC2210N
MSC3210N
MSC4210N
MSC4215N
Battery rated
voltage
12/24VDC ★ Auto-
recognition
24VDC
Rated charging
current
20A
30A
40A
Controller working
voltage range
8~32V
16~32V
Max. PV open
circuit voltage
100V(lowest temperature)
92V(At 25℃ operating
environment temperature)
150V(lowest temperature)
138V(At 25℃ operating
environment temperature)
MPPT voltage
range
(Battery voltage +2V)～
72V
(Battery voltage +2V)～
108V
Rated charging
power
260W/12V
520W/24V
390W/12V
780W/24V
1040W/24V
Max. conversion
efficiency
98.3%
98.6%
98.6%
Full load efficiency
96.4%
96.6%
96.5%
Self-consumption
≤35mA(12V) ≤22mA(24V)
Load 1/2
constant-voltage
output voltage
DC 12V/24V (configurable)
Load rated power
Load 1: 100W
Load 2: 36W
Load output
protection voltage
Load 1: Under Voltage Warning Voltage (it can be set
when the battery type is "USER.")
Load 2: Low Voltage disconnect Voltage (it can be set
when the battery type is "USER.")
Max. load
conversion
efficiency
Load 1 98.9%
Load 2 97.1%
Full load
conversion
efficiency
Load 1 97.4%
Load 2 96.0%
No battery mode
Support
Load output
voltage accuracy
12VDC --load 1: ≤0.4%; load 2: ≤ 0.1%
24VDC --load 1: ≤0.9%; load 2: ≤ 1.1%
Load ripple
voltage
100mV
Load ripple
current
200mA

Epever MPPT Specifications

General

Display	LCD
Type	Solar Charge Controller
Nominal System Voltage	12V/24V Auto (depending on the model)
Max Charging Current	10A to 40A (depending on the model e.g., 10A for Tracer1210AN)
Communication	RS485
Rated Battery Voltage	12V/24V Auto
Protection Features	Over Voltage, Reverse Polarity, Over Discharge, Over Heating, Over Load
Efficiency	Up to 98%
Dimensions	Varies with model.
Model	Tracer AN series (e.g., Tracer1210AN, Tracer2210AN, Tracer3210AN, Tracer4210AN, Tracer1215AN, Tracer2215AN, Tracer3215AN, Tracer4215AN)
