 Table (2): Battery voltage transformation
No.
Code
Battery voltage
Transformation
1
OVD
Over Voltage
Disconnect Voltage
Charge voltage limit + 0.3*Level
2
CLV
Charge Voltage Limit
Voltage
Charge voltage limit (namely, the battery
pack over voltage warning voltage)
3
OVR
Over Voltage
Reconnect Voltage
Charge voltage limit
4
ECV
Equalize Charging
Voltage
Charge voltage limit -0.1* Level
5
BCV
Boost Charging Voltage
Charge voltage limit -0.1* Level
6
FCV
Float Charging Voltage
Charge voltage limit -0.1* Level
7
BVR
Boost Voltage
Reconnect Voltage
Charge voltage limit -0.8* Level
8
LVR
Low Voltage Reconnect
Voltage
Discharge voltage limit +0.7* Level
9
UVR
Under Voltage
Reconnect Voltage
Discharge voltage limit +0.7* Level
10
UVW
Under Voltage Warning
Voltage
Discharge voltage limit +0.4* Level
11
LVD
Low Voltage
Disconnect Voltage
Discharge voltage limit (namely, the battery
pack under voltage warning voltage)
12
DLV
Discharge Voltage Limit
Voltage
Discharge voltage limit -0.7* Level
Note: "Level" is 1 for 12V system, 2 for 24V system, and 4 for 48V system.
3.6 Battery discharge current limit
The function is suitable for the current limiting requirements of lithium batteries.
Abbreviation：
V
BAT
Battery voltage
V
OUT
Inverter output voltage
I
BAT
Actual battery current
UMI
Utility low voltage disconnection voltage
BDC
Battery discharge current limit value(Setting value)
BDC--MAX
Max. Battery discharge current limit value
