Epever UP2000-HM6021 - Page 59

57
 Only UP-Hi with anti-surge function has the surge current parameter.
Item
UP2000-HM6022
UP3000-HM10022
UP3000-HM5042
UP5000-HM8042
Battery Rated Voltage
24VDC
48VDC
Battery Work Voltage Range
21.6~32VDC
43.2~64VDC
Temperature Compensation
-3mV/℃/2V(Default)
Battery Maximum Charging
Current
60A
100A
50A
80A
Inverter Output
Continuous Output Power
2000W
3000W
3000W
5000W
3-second Transient Surge
Output Power
4000W
6000W
6000W
8000W
Inverter Output Voltage
220VAC(-6%~+3%), 230VAC(-10%~+3%)
Inverter Frequency
50/60±0.2%
Output Voltage Waveform
Pure Sine Wave
Load Power Factor
0.2-1(Load power ≤ Continuous output power)
Output Voltage Harmonic
Distortion Rate
≤3%(Resistive load)
Maximum Load Efficiency
91%
91%
90%
91%
Maximum Inverter Efficiency
93%
93%
93%
93%
Switch Response Time
Switch Response Time – Utility to Inverter:10ms
Switch Response Time – Inverter to Utility:15ms
Utility Input
Utility Voltage
176VAC~264VAC (Default), 90VAC~280VAC(Programmable)
Uitility Frequency
40~65Hz
Utility Maximum Charging
Current
60A(When the Utility
input voltage is
90VAC~180VAC, the
Max. utility charge
80A(When the Utility input
voltage is 90VAC~180VAC,
the Max. utility charge
current is 40A）
40A(When the Utility
input voltage is
90VAC~180VAC, the
Max. utility charge
60A(When the Utility input
voltage is 90VAC~180VAC, the
Max. utility charge current is
30A）
