1. Make sure the sheet guide is removed, and set the paper release lever to the single-sheet position.
Also make sure the paper-thickness lever (located under the printer cover) is set to 0.
2. Slide the left paper guide of the cut-sheet feeder so it is aligned with the triangle mark. Next, slide
the right paper guide to roughly match the width of your paper. Slide the paper support midway
between the paper guides.
1. Paper guides
2. Paper support
LQ-590II/LQ-590IIN/LQ-2090II/LQ-2090IIN User’s Guide
Options and Consumables 130
