1. Before loading a paper, make sure the following:
- the printer is turned off
- the printer cover is removed
- the tractor is installed in the pull position
- the sheet guide is lying flat on the printer
2. Set the paper release lever to the pull tractor position.
3. Release the sprockets by pulling the sprocket lock levers forward.
LQ-590II/LQ-590IIN/LQ-2090II/LQ-2090IIN User’s Guide
Paper Handling 34
