Epson Disc producer PP-100N Security

145
Troubleshooting
7
Remove the four screws on the product rear, and then remove the air vent cover.
8
Remove the screw, and then remove the rear printer cover.
9
Grasp the fixture as shown in the figure below, and pull out the printer tray towards you.
