Epson DM-D500 Technical Reference Guide

16
Y connection (Serial)
The Y connection is a connection in which the computer is connected to the customer display via the TM
printer. This is possible when the TM printer is equipped with a DM-D connector, and connected using serial
connection. The power supply is connected to the TM printer.
PS-180
TM Printer
DM-D500 + DP-502
Serial
Computer
TM Printer
PS-180
DM-D500 + DP-501
Computer
Serial
With DP-502
With DP-501
Computer
DM-D500
TM Printer
Serial
Serial
DM-D500 Modular Cable
Data flow in Y
connection
