Epson DS-530 II User Manual

Contents
Copyright
Trademarks
About This Manual
Introduction to the Manuals...................8
Marks and Symbols.........................8
Descriptions Used in this Manual...............8
Operating System References..................8
Important Instructions
Safety Instructions.........................11
Restrictions on Copying.....................12
Product Features
Paper Protection to Reduce Damage to the
Originals................................14
Notication of Dirt on the Sensor..............14
Double-Feed Detection Feature with Selectable
Stop Timing..............................14
High-Quality Scanning with Automatic
Document Detection.......................15
Scanner Basics
Part Names and Functions...................18
Buttons and Lights on the Control Panel.........20
Buttons...............................20
Lights................................21
Error Indicators.........................22
Information on Applications..................22
Application for Scanning Documents
(Document Capture Pro / Document Capture). . 22
Application for Controlling the Scanner
(Epson Scan 2)..........................23
Application for Updating Soware and
Firmware (EPSON Soware Updater). . . . . . . . . 23
Soware for Managing Devices on the
Network (Epson Device Admin).............24
Application for Creating Driver Packages
(EpsonNet SetupManager).................24
Option Items and Consumables Information. . . . . . 24
Carrier Sheet Codes......................24
Roller Assembly Kit Codes.................25
Cleaning Kit Codes...................... 25
Flatbed Scanner Dock Codes...............26
Specications
of Originals and
Placing Originals
Specications of Originals................... 28
General Specications for Originals being
Scanned.............................. 28
Types of Originals that Require Attention. . . . . . 31
Types of Originals that Must Not be Scanned. . . .32
Placing Originals..........................33
Standard Size Originals................... 33
Long Paper............................38
Plastic Cards...........................40
Laminated Cards........................44
Large Size Originals......................46
Irregular Shaped Originals.................49
Photographs........................... 52
Envelopes.............................55
Mixture of Originals......................58
Basic Scanning
Scanning Using a Scanner Button..............62
Scanning from a Computer...................62
Scanning Using Document Capture Pro
(Windows)............................ 62
Scanning Using Document Capture (Mac OS). . . 69
Scanning Using Epson Scan 2...............75
Advanced Scanning
Setting a Job..............................82
Creating and Registering a Job (Windows). . . . . 82
Creating and Registering a Job (Mac OS). . . . . . .88
Assigning a Job to the Scanner Button
(Windows)............................ 89
Assigning a Job to the Scanner Button (Mac OS). 89
Scanning Dierent Sizes or Types of Originals
One by One (Automatic Feeding Mode).........90
Various Scanning Settings for Document
Capture Pro (for Windows Only).............. 91
Dividing documents using a specied
number of pages........................ 92
Dividing documents using blank sheets of paper. 95
Creating and saving folders using the barcode
character information.................... 99
4

Epson DS-530 II Specifications

General

Sleep mode	Yes
Input voltage	24 V
Power supply type	AC
Power consumption (off)	0.1 W
Power consumption (sleep)	1 W
Power consumption (typical)	11 W
Input color depth	30 bit
Maximum scan size	215.9 x 6096 mm
Output color depth	24 bit
Input grayscale depth	10 bit
Output grayscale depth	8 bit
ADF scan speed (b/w, A4)	35 ppm
Optical scanning resolution	600 x 600 DPI
Duplex ADF scan speed (b/w, A4)	70 ipm
Scan to	E-mail, FTP, Software, Print, Network folder
Sensor type	CIS
Scan drivers	TWAIN, WIA, ISIS
Button functions	Scan
Scan file formats	JPEG, PDF, TIFF
Daily duty cycle (max)	4000 pages
Auto document feeder (ADF) input capacity	50 sheets
Minimum scan area (ADF)	50.8 x 50.8 mm
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	27 - 413 g/m²
USB version	3.2 Gen 1 (3.1 Gen 1)
Compatible operating systems	Citrix XenApp 5.0, Citrix XenApp 6.0, Citrix XenApp 7.6 und höher, Linux, Mac OS 10.7.x, Mac OS 10.8.x, Mac OS 10.9.x, Mac OS X, Mac OS X 10.6.8, Windows 10, Windows 7, Windows 7, 64-Bit-Version, Windows 8, Windows 8 (32/64 Bit), Windows 8 RT, Windows 8.1, Windows 8.1 x64 Edition, Windows Server 2008 (32/64 Bit), Windows Server 2008 R2, Windows Server 2012 (64bit), Windows Server 2012 R2, Windows Vista, Windows Vista, 64-Bit-Version, Windows Server 2003 R2, Windows XP Professional x64 Edition
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina
Server operating systems supported	Windows Server 2008, Windows Server 2008 x64, Windows Server 2008 R2, Windows Server 2012 x64, Windows Server 2012 R2, Windows Server 2003 R2
Windows operating systems supported	Windows 10, Windows 7, Windows 7 x64, Windows 8, Windows 8 x64, Windows RT, Windows 8.1, Windows 8.1 x64, Windows Vista, Windows Vista x64, Windows XP Professional x64
Storage temperature (T-T)	25 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	15 - 85 %
Operating relative humidity (H-H)	15 - 80 %
Package depth	365 mm
Package width	250 mm
Package height	290 mm
Package weight	4568 g
Quantity per pack	1 pc(s)
Bundled software	Epson Document Capture (Mac only), Epson Document Capture Pro (Windows only), Epson Document Capture Pro Server (on free download), Epson Scan 2, Presto! BizCard 5.6
Certification	RoHS
Scanner type	Sheet-fed scanner
Product color	Black, White
Built-in display	No
Country of origin	Indonesia
Image formats supported	JPEG, TIFF
Quantity per pallet	63 pc(s)
Quantity per pallet (UK)	84 pc(s)
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	169 mm
Width	296 mm
Height	176 mm
Weight	3700 g
