Epson EB-1485Fi User Manual

Contents
5
Connection Methods for Wireless Network Projection................................................ 162
Installing the Wireless LAN Module..................................................................................... 163
Selecting Wireless Network Settings Manually ............................................................... 164
Selecting Wireless Network Settings in Windows.......................................................... 167
Selecting Wireless Network Settings in Mac .................................................................... 167
Setting Up Wireless Network Security for Simple AP Mode....................................... 167
Setting Up Wireless Network Security for Infrastructure Mode................................ 168
Supported Client and CA Certificates............................................................................ 170
Using a QR Code to Connect a Mobile Device ................................................................ 170
Using a USB Key to Connect a Windows Computer...................................................... 171
Wireless Network Projection from a Mobile Device (Screen
Mirroring)........................................................................................ 172
Selecting Screen Mirroring Settings .................................................................................... 172
Connecting Using Screen Mirroring with the Miracast Function............................. 174
Connecting Using Screen Mirroring in Windows 10..................................................... 175
Connecting Using Screen Mirroring in Windows 8.1 .................................................... 175
Secure HTTP.................................................................................... 177
Importing a Web Server Certificate Using the Menus .................................................. 177
Supported Web Server Certificates................................................................................ 178
Screen Sharing ............................................................................... 179
Preparing For Screen Sharing ................................................................................................ 179
Sharing the Screen ..................................................................................................................... 180
Receiving Shared Screen Images.......................................................................................... 181
Monitoring and Controlling the Projector 182
Epson Projector Management ...................................................... 183
Controlling a Networked Projector Using a Web Browser ........ 184
Web Control Options................................................................................................................. 185
Registering Digital Certificates from a Web Browser................. 189
Setting Up Projector Network E-Mail Alerts ............................... 190
Network Projector E-mail Alert Messages ......................................................................... 190
Setting Up Monitoring Using SNMP............................................. 191
Using ESC/VP21 Commands ........................................................ 192
ESC/VP21 Command List ......................................................................................................... 192
Cable Layouts ............................................................................................................................... 192
PJLink Support ............................................................................... 193
Crestron Connected Support........................................................ 194
Setting Up Crestron Connected Support........................................................................... 194
Controlling a Networked Projector Using Crestron Connected ............................... 194
Crestron Connected Operation Window ..................................................................... 196
Crestron Connected Tools Window ............................................................................... 197
Setting Projector Event Schedules............................................... 199
Adjusting the Menu Settings 202
Using the Projector's Menus ......................................................... 203
Using the Displayed Keyboard..................................................... 204
Available Text Using the Displayed Keyboard................................................................. 204
Image Quality Settings - Image Menu ......................................... 205
Input Signal Settings - Signal I/O Menu....................................... 207
Projector Installation Settings - Installation Menu .................... 209
Projector Display Settings - Display Menu.................................. 211
Projector Feature Settings - Operation Menu............................. 213
Projector Administration Settings - Management Menu .......... 215
Event ID Code List....................................................................................................................... 217
Projector Network Settings - Network Menu.............................. 219
Network Menu - Network Settings Menu.......................................................................... 220
Network Menu - Wireless LAN Menu............................................................................. 221
Network Menu - Wired LAN Menu ................................................................................. 223
Network Menu - Mail Notification Menu ..................................................................... 224
Network Menu - Projector Control Menu .................................................................... 224

Epson EB-1485Fi Specifications

General

Matrix size	0.62 \
Heat dissipation	1244 BTU/h
Number of colors	1.07 billion colors
Native aspect ratio	16:9
Projection distance	0 - 0.78 m
Vertical scan range	192 - 240 Hz
Projection technology	3LCD
Contrast ratio (typical)	2500000:1
Screen size compatibility	65 - 100 \
Projection distance (tele)	0 - 0.6 m
Projection distance (wide)	0 - 0.4 m
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-3 - 3 °
Projector brightness (economic mode)	3500 ANSI lumens
Focus	Manual
Throw ratio	0.27 - 0.37:1
Zoom capability	Yes
Fixed focal length	3.9 mm
Power source	AC
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	366 W
Power consumption (economy mode)	262 W
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
DVI port	No
Composite video in	0
HDMI connector type	Full-size
HDMI ports quantity	3
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Component video (YPbPr/YCbCr) in	1
Mobile High-Definition Link (MHL)	-
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Noise level	36 dB
Country of origin	China
Interactive input supported	Interactive pen/Touch
Noise level (economic mode)	27 dB
Compatible operating systems	Linux, Mac OS 10.10.x, Mac OS 10.7.x, Mac OS 10.8.x, Mac OS 10.9.x, Ubuntu 14.10, Ubuntu 15.04, Windows 10, Windows 10 (32/64 bit), Windows 2000
Placement	Wall
Product type	Ultra short throw projector
Product color	White
Market positioning	Business
Cable lock slot type	Kensington
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB, DICOM simulation mode
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
RMS rated power	16 W
Storage temperature (T-T)	-10 - 60 °C
Bundled software	Easy Interactive Tools, EasyMP Multi PC Projection, Epson Projektor Management
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	6 pc(s)
Quantity per pallet (UK)	12 pc(s)
Harmonized System (HS) code	85286200
Supported network protocols	HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink
Sustainability certificates	TCO
Software support	via: AMX, Crestron (Network), Extron, Crestron (RS-232C only), Crestron Integrated Partner, Crestron RoomView, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol
Windows operating systems supported	Windows 10, Windows 10 x64, Windows 2000

Weight and Dimensions

Depth	375 mm
Width	458 mm
Height	210 mm
Weight	9300 g
Package depth	590 mm
Package width	472 mm
Package height	640 mm
Package weight	27700 g
