Epson EB-G7905UNL User Manual

Submenu Function
Pattern Guide
Set to On to display a guide to match the position of
the Edge Blending setting range.
Guide Colors
Select a combination of guide colors from the three
provided.
d
Turn on Edge Blending.
(1)
Select Edge Blending, and then press the [
] button.
(2)
Select On, and then press the [
] button.
(3) Press the [Esc] button.
e
Set Guide Display to On.
(1)
Select Guide Display, and then press the [
] button.
(2)
Select On, and then press the [
] button.
(3) Press the [Esc] button.
a
If the guide is not clear, you can change the color of the guide
on Guide Colors.
f
Set Pattern Guide to On.
(1)
Select Pattern Guide, and then press the [
] button.
(2)
Select On, and then press the [
] button.
(3) Press the [Esc] button.
g
Set Top Edge, Bottom Edge, Left Edge, or Right Edge according
to the parts of the image that are overlapped.
The following shows how to set screen (1) as an example.
In the example above, you need to adjust the Left Edge because you
can see the overlapping areas on the left side of the image (1).
(1)
Select Left Edge, and then press the [
] button.
(2)
Select Blending, and then press the [
] button.
(3)
Select On, and then press the [
] button.
(4) Press the [Esc] button.
(5) In Blend Start Position, align the blending start position with the edge (2)
of the image.
(6) Press the [Esc] button.
(7) In Blend Range, adjust the range (3) to be shaded.
The value for when the overlapped range and the guide are in the same
position is the best.
(8) Press the [Esc] button.
Multi-Projection Function
104
