d
While holding the lens unit firmly, hold the lock lever and turn it
clockwise to lock the lens unit.
Check that the lens cannot be detached.
e
Attach the lens replacement cover.
Lens Calibration
After replacing the lens unit, calibrate the lens so that the projector can
correctly acquire the lens position and adjustment range.
After attaching a lens unit with a different model number to the previous
one, a message is displayed when the projector is turned on.
Select Yes to calibrate the lens.
Lens calibration takes up to about 100 seconds until it is complete. When it
is complete, the lens position returns to the position before the calibration
(ELPLX01 returns to the standard position).
Attention
If the message "Lens Calibration failed." is displayed, stop using the projector,
remove the power plug from the electrical outlet, and contact your local
dealer or the nearest address provided in the Epson Projector Contact List.
s Epson Projector Contact List
a
• You can also calibrate the lens from the Configuration menu.
s Extended - Operation - Lens Calibration p.140
• If no message is displayed after attaching the lens unit, perform lens
calibration from the Configuration menu.
• If you do not calibrate the lens, the following functions may not
operate correctly.
Focus, Distortion, Zoom, Lens Shift, Memory (Lens Position)
Installing the Projector
27
