Epson EB-G7905UNL User Manual

h
Select Location Setup, and then press the [ ] button.
(1) Set the positions of the projected images in Row Order and Column
Order.
Row Order: Place screens from top to bottom in the order of 1, 2, 3.
Column Order: Place screens from left to right in the order of A, B, C.
(2)
Select Set, and then press the [
] button.
i
Repeat step 8 for each projector.
j
Input the image signal to display the image.
s "Automatically Detecting Input Signals and Changing the
Projected Image (Source Search)" p.59
k
Set Scale to Auto.
(1) Select Multi-Projection from Extended.
(2)
Select Scale, and then press the [
] button.
(3)
Select Auto from Scale, and then press the [
] button.
The scale and clip range are automatically set according to the
blending width.
l
Fine tune the overlapping areas of the screens.
s "Correcting Distortion in the Projected Image" p.62
s
"Adjust the Edges of the Images (Edge Blending)" p.103
Displaying a Scaled Image
A section of the image is cropped and displayed. This allows you to create
one large image by combining images projected from multiple projectors.
a
Project the image, and then press the [Menu] button.
s "Using the Configuration Menu" p.134
b
Select Multi-Projection from Extended.
a
You can also perform the same operation from Scale in
Signal.
c
Select Scale, and then press the [ ] button.
Multi-Projection Function
112
