Signal Refresh Rate (Hz) Resolution (Dots)

WXGA++ 60 1600x900

WSXGA+

60 1680x1050

SXGA

60 1280x960

60 1280x1024

SXGA+ 60 1400x1050

UXGA 60 1600x1200

WUXGA

60 1920x1200

QXGA

60 2048x1536

WQHD

60 2560x1440

WQXGA

60 2560x1600

SDTV (480i/480p) 60 720x480

SDTV (576i/576p) 50 720x576

HDTV (720p) 50/60 1280x720

HDTV (1080i) 50/60 1920x1080

HDTV (1080p) 24/30/50/60 1920x1080

4Kx2K

24/25/30/50/60 3840x2160

4Kx2K (SMPTE)

24/50/60 4096x2160

*1 When an HDMI connection is made using the optional HDBaseT Transmitter.

*2 EB-G7905U/EB-G7900U/EB-G7500U/EB-G7400U/EB-G7200W/EB-G7000W

only.

*3 Only compatible when VESA CVT-RB (Reduced Blanking) signal is input.

*4 EB-G7905U/EB-G7900U/EB-G7500U/EB-G7400U only. Only for HDMI input.

Supported Monitor Displays

239

Notations Used in this Guide2
- Table of Contents9
