Projection Distance for EB-G7800
A
Projection distance
B
is the distance from the center of the lens to the base of the screen. This
changes depending on the setting for vertical lens shift.
C
Center of lens
ELPLM08
This section shows the projection distances for models equipped with
standard lenses.
Unit: cm
4:3 Screen Size
AB
Minimum (Wide) to
Maximum (Tele)
Vertical Lens Shift
Bottom to Top
50" 102x76 147 to 239 -82 to +6
60" 122x91 178 to 288 -98 to +7
80" 163x122 239 to 385 -131 to +9
100" 203x152 299 to 482 -164 to +12
120" 244x183 360 to 580 -197 to +14
150" 305x229 452 to 726 -246 to +17
200" 406x305 604 to 969 -328 to +23
250" 508x381 756 to 1213 -410 to +29
300" 610x457 908 to 1456 -492 to +35
Unit: cm
16:9 Screen Size
AB
Minimum (Wide) to
Maximum (Tele)
Vertical Lens Shift
Bottom to Top
46" 102x57 148 to 240 -73 to +15
50" 111x62 161 to 261 -79 to +17
60" 133x75 194 to 314 -95 to +20
80" 177x100 260 to 420 -126 to +27
100" 221x125 327 to 526 -158 to +33
120" 266x149 393 to 632 -189 to +40
150" 332x187 493 to 791 -237 to +50
200" 443x249 658 to 1057 -316 to +67
250" 553x311 824 to 1322 -395 to +83
275" 609x342 907 to 1454 -434 to +92
Screen Size and Projection Distance
226
