h
Adjust the position of the projector and the lens shift so that the
line in the center of the screen matches the corner (the point
where the two surfaces meet).
s "Adjusting the Position of the Projected Image (Lens Shift)"
p.33
a
Each time you press the [ ] button, you can show or hide the
image and the grid.
i
Use the [ ], [ ], [ ], and [ ] buttons to select the area you
want to adjust, and then press the [
] button.
Adjustment tips
When Horizontal Corner is selected:
Adjust the upper area based on the lowest point (indicated by the
U
arrow).
Adjust the lower area based on the highest point (indicated by the
V
arrow).
A
B
Adjusting Projected Images
84
