b
Select one of the following, and then press the [ ] button.
Off: Disables 4K Enhancement. If a signal that exceeds the panel
resolution of this projector is input, the image is displayed according
to the panel resolution of this projector.
Full HD: If a signal with a resolution of 1080i/1080p/WUXGA or
higher is input, 4K Enhancement is enabled.
WUXGA+: If a signal with a resolution that exceeds WUXGA is
input, 4K Enhancement is enabled. To project a high-resolution
movie, you can project a high-definition image by using this setting
with Image Preset Mode.
a
• To project from multiple projectors, select Off to unify each
image.
• Off is ideal for projecting presentation materials from
computers and so on.
• If set to Full HD or WUXGA+, the status corrected using the
following function is canceled.
Edge Blending, Scale, Curved Surface, Point Correction,
Corner Wall
When 4K Enhancement is set to Off, the settings returns to
the previous state.
• If 4K Enhancement is enabled and the surrounding
temperature gets high, the lamp may automatically dim.
c
Press the [Esc] button to return to the previous screen.
Image Preset Mode
Select the optimal setting according to the projected image from five presets
prepared in advance.
The following settings are saved in the presets.
Noise Reduction, MPEG Noise Reduction, Super-resolution, Detail
Enhancement
a
Select Image Preset Mode from Image Enhancement, and then
press the [
] button.
b
Select one of the following, and then press the [ ] button.
Preset 1 to Preset 5: The settings saved in advance are applied to the
image.
Off: Select this to turn off presets.
a
• After selecting Preset 1 to Preset 5, you can fine tune each
setting individually. The setting after adjustment will be
overwritten.
• The setting after adjustment will be overwritten separately
when 4K Enhancement is enabled and disabled.
c
Press the [Esc] button to return to the previous screen.
Adjusting Projected Images
98
