The following screen is displayed.
Half of the overlapped area is displayed in black so that it is easy to
check the edge of the image.
Adjustment Level: There are eight levels from white, through gray,
and up to black. Adjust each level individually.
Red, Green, Blue: Adjusts the tone for each color.
Brightness: Adjusts the image brightness.
a
Whenever the [ ] button is pressed, the screen changes
between the projected image and the adjustment screen.
b
Select Adjustment Level, and then use the [ ][ ] buttons to set
the adjustment level.
c
Select Red, Green, or Blue, and then press the [ ][ ] buttons to
adjust the color tone.
d
Select Brightness, and then use the [ ][ ] buttons to adjust the
brightness.
e
Return to step 2 and adjust each level.
f
Press the [Esc] button to return to the previous screen.
Adjusting RGBCMY
The Hue, Saturation, and Brightness for each of the R (red), G (green), B
(blue), C (cyan), M (magenta) and Y (yellow) color components can be
adjusted.
After adjustment using Color Matching, adjust if you are concerned about
differences of the colors.
s
"Hue, Saturation, and Brightness adjustment" p.92
Multi-Projection Function
107
