The areas are displayed based on the settings for Top Edge/Bottom
Edge/Right Edge/Left Edge.
c
Select the area you want to adjust, and then press the [ ]
button.
The selected area is displayed in orange.
a
When multiple screens are overlapping, adjust based on the area
with the most overlap (the brightest area). In the illustration
below, first align (2) with (1), and then adjust so that (3) aligns
with (2).
d
Adjust the black tone and brightness.
e
Repeat steps 3 and 4 as needed to adjust any remaining parts.
After this, if the tone for some areas do not match, adjust them by
Area Correction.
f
Press the [Esc] button, to return to the screen displayed in step
2.
g
Select Area Correction, and then press the [ ] button.
h
Select Start Adjustments, and then press the [ ] button.
Multi-Projection Function
109
