Epson EB-L1105U User Manual

H/V-Keystone
s "H/V-Keystone" p.63
For projectors with a built-in lens, the lens varies depending on the model.
EB-L1505U/EB-L1500U: ELPLM09
EB-L1405U/EB-L1300U/EB-L1200U/EB-L1105U/EB-L1100U/EB-L1000U:
ELPLM08
EB-L1505U/EB-L1500U
Lens type Vertical Horizontal
ELPLU03 -31˚ to 31˚ -30˚ to 30˚
ELPLU04/ELPLU02 -31˚ to 31˚ -30˚ to 30˚
ELPLR04 -31˚ to 31˚ -30˚ to 30˚
ELPLW05 -41˚ to 41˚ -30˚ to 30˚
ELPLW06/ELPLW04 -41˚ to 41˚ -30˚ to 30˚
ELPLM09/ELPLS04 -44˚ to 44˚ -30˚ to 30˚
ELPLM10/ELPLM06 -45˚ to 45˚ -30˚ to 30˚
ELPLM11/ELPLM07 -45˚ to 45˚ -30˚ to 30˚
ELPLL08/ELPLL07 -45˚ to 45˚ -30˚ to 30˚
EB-L1405U/EB-L1300U/EB-L1200U/EB-L1105U/EB-L1100U/EB-
L1000U
Lens type Vertical Horizontal
ELPLX01 -16˚ to 16˚ -16˚ to 16˚
ELPLU03 -28˚ to 28˚ -28˚ to 28˚
ELPLU04/ELPLU02 -35˚ to 35˚ -30˚ to 30˚
ELPLR04 -34˚ to 34˚ -30˚ to 30˚
Lens type Vertical Horizontal
ELPLW05 -40˚ to 40˚ -30˚ to 30˚
ELPLW06/ELPLW04 -45˚ to 45˚ -30˚ to 30˚
ELPLM08 -45˚ to 45˚ -30˚ to 30˚
ELPLM09/ELPLS04 -45˚ to 45˚ -30˚ to 30˚
ELPLM10/ELPLM06 -45˚ to 45˚ -30˚ to 30˚
ELPLM11/ELPLM07 -45˚ to 45˚ -30˚ to 30˚
ELPLL08/ELPLL07 -45˚ to 45˚ -30˚ to 30˚
Curved Surface
s
"Curved Surface" p.65
For projectors with a built-in lens, the lens varies depending on the model.
EB-L1505U/EB-L1500U: ELPLM09
EB-L1405U/EB-L1300U/EB-L1200U/EB-L1105U/EB-L1100U/EB-L1000U:
ELPLM08
The values in the table are the minimum values for R/L in the illustration.
(Approximate value when projecting at maximum zoom. ELPLR04 does
not support lens shift.)
Adjustment Range for Projected Images
230
