Wireless Network Projection from a Mobile Device (Screen Mirroring)
145
You can send image to your projector from mobile devices such as laptops,
smartphones, and tablets using Miracast technology.
You can connect two devices that use Miracast technology at the same time.
The projector detects the input sources as Screen Mirroring1 and Screen
Mirroring2. You need to set the Interrupt Connection setting to Off.
s Network > Network Settings > Network Projection > Screen Mirroring
> Interrupt Connection
If your device supports Miracast, you do not need to install any additional
software. When using a Windows computer, make sure the necessary adapter
for the Miracast connection is available.
Note the following limitations when using Screen Mirroring features.
• You cannot play an interlaced image.
• You cannot play multi-channel audio over 3ch (channel 3).
• You may not be able to project images depending the resolution and frame
rate.
• You cannot play 3D video.
• You may not be able to view contents with copyright protection with a
Miracast connection depending on your device.
• Do not change the projector's Screen Mirroring setting during Screen
Mirroring projection. Doing so may cause the projector to disconnect and it
may take a while to re-connect.
s Network > Network Settings > Network Projection > Screen
Mirroring
• Do not turn off the projector directly by the breaker during Screen
Mirroring projection.
a
Mobile devices with Android installed or Windows 8.1 or later installed
mainly support Miracast.
Support for Miracast varies depending on the mobile device. See your
mobile device manual for details.
gg Related Links
• "Selecting Screen Mirroring Settings" p.145
• "Connecting Using Screen Mirroring with the Miracast Function" p.147
• "Connecting Using Screen Mirroring in Windows 10" p.148
• "Connecting Using Screen Mirroring in Windows 8.1" p.148
Selecting Screen Mirroring Settings
You must select Screen Mirroring settings for your projector to project
images from your mobile device.
a
If you use Windows 10, you can cast images using the following
connections:
• Casting images from your device to the projector directly
• Casting images via local area network
When you cast images via local area network, the connection is more
stable and secure. Do one of the following to connect your projector to
a local area network:
• Connect a LAN cable.
• Select the Wireless LAN setting to connect to the wireless access
point.
To connect to a wireless access point, you need to install the optional
wireless LAN module.

Epson EB-L520U Specifications

General

Matrix size	0.67 \
Number of colors	1.07 billion colors
Native aspect ratio	16:10
Vertical scan range	192 - 240 Hz
Projection technology	3LCD
Contrast ratio (typical)	2500000:1
Screen size compatibility	50 - 500 \
Projector native resolution	WUXGA (1920x1200)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	3640 ANSI lumens
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Focus	Manual
Throw ratio	1.35 - 2.2:1
Zoom capability	Yes
Focal length range	20 - 31.8 mm
Aperture range (F-F)	1.5 - 1.7
3D	No
Video processing	10 bit
Video color modes	Cinema, Dynamic, Presentation, sRGB, DICOM simulation mode
Analog signal format system	Not supported
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
USB 2.0 Type-B ports quantity	1
Wi-Fi standards	802.11a, Wi-Fi 4 (802.11n)
Noise level	31 dB
Country of origin	Philippines
Noise level (economic mode)	23 dB
RMS rated power	10 W
Placement	Ceiling, Desktop, Floor, Wall
Product type	Standard throw projector
Product color	White
Market positioning	Presentation
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	293 W
Power consumption (economy mode)	223 W
Storage temperature (T-T)	-10 - 60 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, HDMI
Bundled software	EasyMP Multi PC Projection
USB display function	3 in 1: Image / Mouse / Sound
Sustainability certificates	TCO
Software support	via: AMX, Crestron (Network), Control4, Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	14 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	122 mm
Width	440 mm
Height	304 mm
Weight	7700 g
Package depth	530 mm
Package width	540 mm
Package height	210 mm
Package weight	10450 g
