Using the Manual to Search for Information
9
The PDF manual allows you to search for information you are looking for by
keyword, or jump directly to specific sections using the bookmarks. You can
also print only the pages you need. This section explains how to use a PDF
manual that has been opened in Adobe Reader X on your computer.
gg Related Links
"Searching by Keyword" p.9
"Jumping Directly from Bookmarks" p.9
"Printing Only the Pages You Need" p.9
Searching by Keyword
Click Edit > Advanced Search. Enter the keyword (text) for information you
want to find in the search window, and then click Search. Hits are displayed
as a list. Click one of the displayed hits to jump to that page.
Jumping Directly from Bookmarks
Click a title to jump to that page. Click + or > to view the lower level titles in
that section. To return to the previous page, perform the following operation
on your keyboard.
Windows: Hold down Alt, and then press .
Mac OS: Hold down the command key, and then press .
Printing Only the Pages You Need
You can extract and print only the pages you need. Click Print in the File
menu, and then specify the pages you want to print in Pages in Pages to
Print.
To specify a series of pages, enter a hyphen between the start page and the
end page.
Example: 20-25
To specify pages that are not in series, divide the pages with commas.
Example: 5, 10, 15

Table of Contents

Other manuals for Epson EB-L520U

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-L520U and is the answer not in the manual?

Epson EB-L520U Specifications

General IconGeneral
Matrix size0.67 \
Number of colors1.07 billion colors
Native aspect ratio16:10
Vertical scan range192 - 240 Hz
Projection technology3LCD
Contrast ratio (typical)2500000:1
Screen size compatibility50 - 500 \
Projector native resolutionWUXGA (1920x1200)
Keystone correction, horizontal-30 - 30 °
Projector brightness (economic mode)3640 ANSI lumens
Light source typeLaser
Service life of light source20000 h
Service life of light source (economic mode)30000 h
FocusManual
Throw ratio1.35 - 2.2:1
Zoom capabilityYes
Focal length range20 - 31.8 mm
Aperture range (F-F)1.5 - 1.7
3DNo
Video processing10 bit
Video color modesCinema, Dynamic, Presentation, sRGB, DICOM simulation mode
Analog signal format systemNot supported
Serial interface typeRS-232C
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity3
USB 2.0 Type-B ports quantity1
Wi-Fi standards802.11a, Wi-Fi 4 (802.11n)
Noise level31 dB
Country of originPhilippines
Noise level (economic mode)23 dB
RMS rated power10 W
PlacementCeiling, Desktop, Floor, Wall
Product typeStandard throw projector
Product colorWhite
Market positioningPresentation
Cable lock slot typeKensington
Power sourceAC
AC input voltage100-240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.3 W
Power consumption (typical)293 W
Power consumption (economy mode)223 W
Storage temperature (T-T)-10 - 60 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
Cables includedAC, HDMI
Bundled softwareEasyMP Multi PC Projection
USB display function3 in 1: Image / Mouse / Sound
Sustainability certificatesTCO
Software supportvia: AMX, Crestron (Network), Control4, Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol
Pallet weight0 g
Quantity per pack1 pc(s)
Quantity per pallet14 pc(s)
Harmonized System (HS) code85286200
Weight and Dimensions IconWeight and Dimensions
Depth122 mm
Width440 mm
Height304 mm
Weight7700 g
Package depth530 mm
Package width540 mm
Package height210 mm
Package weight10450 g
