Epson EB-L520U User Manual

Contents
6
Viewing the Status Display ........................................................... 226
Projector Status Display Messages....................................................................................... 226
Solving Image or Sound Problems............................................... 229
Solutions When No Image Appears..................................................................................... 229
Solutions When "No Signal" Message Appears............................................................... 229
Displaying From a Windows Laptop.............................................................................. 230
Displaying From a Mac Laptop........................................................................................ 230
Solutions When "Not Supported" Message Appears .................................................... 230
Solutions When Only a Partial Image Appears................................................................ 230
Solutions When the Image is not Rectangular................................................................ 231
Solutions When the Image Contains Noise or Static..................................................... 231
Solutions When the Image is Fuzzy or Blurry .................................................................. 232
Solutions When the Image Brightness or Colors are Incorrect ................................. 233
Solutions When an Afterimage Remains on the Projected Image .......................... 233
Solutions to Sound Problems................................................................................................. 233
Solutions When Image File Names are not Displayed Correctly in PC Free......... 234
Solutions When You Cannot Project Images Using the PC Free Feature.............. 234
Solving Projector or Remote Control Operation Problems....... 235
Solutions to Projector Power or Shut-Off Problems...................................................... 235
Solutions to Problems with the Remote Control............................................................ 235
Solutions to Password Problems........................................................................................... 236
Solution When "The Battery that Saves Your Clock Settings is Running Low"
Message Appears........................................................................................................................ 236
Solving Network Problems ........................................................... 237
Solutions When Wireless Authentication Fails ................................................................ 237
Solutions When You Cannot Access the Projector Through the Web ................... 237
Solutions When Network Alert E-Mails are not Received............................................ 237
Solutions When the Image Contains Static During Network Projection............... 238
Solutions When You Cannot Connect Using Screen Mirroring................................. 238
Solutions When You Cannot Use Two Screen Mirroring Sources............................ 238
Solutions When the Image or Sound Contains Static During Screen Mirroring
Connection.................................................................................................................................... 239
Solutions When You Cannot Receive Shared Images................................................... 239
Solutions to Problems in Content Playback Mode ..................... 240
Solutions When HDMI Link does not Function ........................... 241
Appendix 242
Optional Accessories and Replacement Parts............................. 243
Screens............................................................................................................................................ 243
Cables .............................................................................................................................................. 243
Mounts............................................................................................................................................ 243
For Wireless Connection .......................................................................................................... 243
External Devices .......................................................................................................................... 243
Replacement Parts...................................................................................................................... 244
Screen Size and Projection Distance............................................ 245
EB‑L735U/EB‑L730U/EB‑L635SU/EB‑L630SU/EB‑L630U/EB‑L530U........................... 245
EB‑L720U/EB‑L520U ................................................................................................................... 248
Supported Monitor Display Resolutions ..................................... 250
Projector Specifications ................................................................ 254
Connector Specifications ......................................................................................................... 255
External Dimensions...................................................................... 256
Supported Features for Epson Projector Content Manager...... 257
Supported Features for the Epson Projector Professional Tool 258
List of Safety Symbols and Instructions ...................................... 259
Laser Safety Information............................................................... 261
Laser Warning Labels................................................................................................................. 261
Glossary .......................................................................................... 263
Notices ............................................................................................ 265
FCC Compliance Statement.................................................................................................... 265
Indication of the manufacturer and the importer in accordance with
requirements of EU directive.................................................................................................. 266
Restriction of Use........................................................................................................................ 266
Operating System References................................................................................................ 266
Trademarks.................................................................................................................................... 266

Epson EB-L520U Specifications

General

Matrix size	0.67 \
Number of colors	1.07 billion colors
Native aspect ratio	16:10
Vertical scan range	192 - 240 Hz
Projection technology	3LCD
Contrast ratio (typical)	2500000:1
Screen size compatibility	50 - 500 \
Projector native resolution	WUXGA (1920x1200)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	3640 ANSI lumens
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Focus	Manual
Throw ratio	1.35 - 2.2:1
Zoom capability	Yes
Focal length range	20 - 31.8 mm
Aperture range (F-F)	1.5 - 1.7
3D	No
Video processing	10 bit
Video color modes	Cinema, Dynamic, Presentation, sRGB, DICOM simulation mode
Analog signal format system	Not supported
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
USB 2.0 Type-B ports quantity	1
Wi-Fi standards	802.11a, Wi-Fi 4 (802.11n)
Noise level	31 dB
Country of origin	Philippines
Noise level (economic mode)	23 dB
RMS rated power	10 W
Placement	Ceiling, Desktop, Floor, Wall
Product type	Standard throw projector
Product color	White
Market positioning	Presentation
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	293 W
Power consumption (economy mode)	223 W
Storage temperature (T-T)	-10 - 60 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, HDMI
Bundled software	EasyMP Multi PC Projection
USB display function	3 in 1: Image / Mouse / Sound
Sustainability certificates	TCO
Software support	via: AMX, Crestron (Network), Control4, Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	14 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	122 mm
Width	440 mm
Height	304 mm
Weight	7700 g
Package depth	530 mm
Package width	540 mm
Package height	210 mm
Package weight	10450 g
