Epson EB-W06 User Manual

List of Functions
EB‑‑992F/EB‑‑982W/EB‑‑W49/EB‑‑FH52/EB‑‑W52/EB‑‑W51/EB‑‑FH06/EB‑‑W06
The following table lists the functions supported by each projector model. Supported functions are indicated by a "✓" mark.
EB-992F EB-982W EB-W49 EB-FH52 EB-W52 EB-W51 EB-FH06 EB-W06
Resolution Full HD WXGA WXGA Full HD WXGA WXGA Full HD WXGA
1920×1080 1280×800 1280×800 1920×1080 1280×800 1280×800 1920×1080 1280×800
Wired LAN ✓ ✓ ✓ - - - - -
Wireless LAN (built-in) ✓ - - ✓ ✓ - - -
Wireless LAN (optional) - ✓ ✓ - - ✓ ✓ ✓
Screen Mirroring ✓ - - ✓ - - - -
HDMI1/HDMI2 ports ✓ ✓ ✓ ✓ - - ✓ -
HDMI port - - - - ✓ ✓ - ✓
Computer1/Computer2 ports ✓ ✓ ✓ - - - - -
Computer port - - - ✓ ✓ ✓ ✓ ✓
Video port ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
USB-A port ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
USB-B port ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
L-Audio-R ports ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
Audio 1/Audio 2 ports ✓ ✓ ✓ - - - - -
Mic port ✓ ✓ - - - - - -
Monitor Out port ✓ ✓ ✓ - - - - -
Audio Out port ✓ ✓ ✓ - - - - -
RS-232C port ✓ ✓ ✓ - - - - -
Lens cover ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
Horizontal keystone slider ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
Zoom ring ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
Document camera (optional) ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓

Epson EB-W06 Specifications

General

Contrast Ratio	16, 000:1
Weight	2.5 kg
Projection System	3LCD
Aspect Ratio	16:10
Projection Ratio	1.30 - 1.56:1
Screen Size	33 inches - 320 inches
Projection Lens F Number	1.49 - 1.72
Projection Lens Focal Length	16.9 - 20.28 mm
Projection Lens Focus	Manual
Security	Kensington lock, Password protection
3D	No
Resolution	WXGA (1280 x 800)
Brightness	3700 lumens
Lamp Life	12000 hours (Eco)
Keystone Correction	Vertical: ±30 degrees, Horizontal: ±30 degrees
Connectivity	HDMI, VGA, USB
LCD Panel	0.59-inch with MLA (D10)
Lamp	UHE, 210 W
Zoom	Factor: 1.2
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption	0.3 W (Standby)
